The Hercules System is our most robust, leakproof cover—engineered to handle high winds, heavy snow, and intense sun.
The Hercules System is our most robust, leakproof cover—engineered to handle high winds, heavy snow, and intense sun.
Sheet Width: 23%”
Sheet Length: We stock pergola cover sheets up to 36′ and can provide lengths up to 52′. Orders over 36′ just need a few extra shipping steps, so those are completed through a sales rep instead of online.
Thickness: 8mm
Colors: 3 standard colors in stock; Bronze, Clear, and White. Custom colors upon request.
Sheet Structure: 4 wall standing seam
Warranty: 10 year leakproof at the seams
Once you place your order, you’ll get an email with all the shipping details.
Sheets will arrive in the full length you ordered, so we recommend preparing a place to store them out of direct sunlight and away from dirt, debris, and moisture until installation.
The Hercules System is designed to be DIY-friendly if you’re handy, and most installs can be wrapped up in less than a day. We’ve got step-by-step videos and printed guides to walk you through it, plus our team is always just a call away if you have questions. Once installed, the cover requires minimal maintenance.
We make it simple-every order ships with all the parts you’ll need to install.
For best performance from the Hercules System, we have a couple of structure requirements. This makes sure your system won’t leak and will perform to its full potential in high winds and heavy snow loads.
The Hercules System works best on pergolas with purlins. Since the panels can’t be trimmed, rafters need to be spaced at an exact 23 ¾”. Depending on your pergola’s slope and your design preferences, there are multiple ways to modify the structure for a successful installation.
Rafters are the main structural beams that run across the pergola, usually larger and spaced farther apart. They give the pergola its strength and framework.
Shade slats (also called purlins) are the smaller boards that sit on top of or across the rafters. They don’t add much structure, but they create extra shade and a more finished look overhead.
If your structure isn’t ready for the Hercules System yet, no worries! We’ve got step-by-step guides for common scenarios, and our team’s always here to chat about your specific pergola setup.
Download GuideDownload GuideDownload Guide
The Hercules System is rated for snow loads up to 50 PSF when purlins are spaced 23″ or less. For comparison, most home roofs are rated between 20–30 PSF.
The Hercules System is rated to withstand wind speeds up to 139 mph when installed correctly. For best performance, make sure your purlins are spaced less than 19″ apart and the cover is secured to the structure with screws (not nails).
Check out our downloadable PDF and video—and don’t worry, your system also comes with a printed copy in the box.
Find answers to frequently asked questions
about Hercules System.
Cleaning is easy! a hose will get mostly everything off. In the case of tree sap, regular diluted dish soap and water do the trick.
With good airflow, there should be no issues. SkyPoly multiwall polycarbonate rocks a Class A fire rating and won’t melt, no matter how hot things get.
Most people can get their cover installed in less than a day.
